Ai/Ni 3u'' Multi Layer Circuit Board FR4 TG150 SMT Assembly PCB
Abis Circuits Co., Ltd is a professional PCB manufacturer in China, Shenzhen. With 14 years+ development, we could make the PCB from 1L to 20L, with monthly production capability of 60,000 square meters. Abis Circuits is providing high-quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating, and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.
Product details:
1. Single, Double side & Multi-layer PCB.
2. Buried/Blind Vias, Via in Pad, Counter Sink Hole, Screw Hole(Counterbore), Press-fit, Half Hole.
3. HASL lead-free, Immersion Gold/ Silver/Tin, OSP, Gold plating/finger, Peelable mask,
4. Printed Circuit Boards adhere to IPC Class 2 & 3 international PCB standard.
5. Quantities range from prototype to medium&big batch production.
Capacity:
| Raw material | FR-4, High TG FR-4, PTFE, Aluminum Base, Cu base. Rogers, etc |
| Board Thickness | 0.20mm--8.00mm |
| Layer | 1 Layer-20 Layer |
| Insulation Layer Thickness | 0.075mm--5.00mm |
| Min.hole size | 0.1mm (drilling hole) |
| Max. Board size | 1200mm*600mm |
| Out Layer Copper Thickness | 18um--350um |
| Inner Layer Copper Thickness | 17um--175um |
| NPTH Hole Tolerance | +/- 0.075mm |
| PTH hole Tolerance | +/-0.05mm |
| Outline tolerance | +/-0.13mm |
| Surface finished | HASL, ENIG, Chem. Tin, Flash Gold, OSP, Gold finger |
| Solder Mask Type | LPI |
| Others | RFQ. |
| Monthly Capacity |
| Small volume and quick turn | Reached 12,000 sqm per month, 2000+ types quick turn PCB in 2018. |
| |
| High volume | Reached 60,000 sqm per month in 2018 |
| |
| 2019 plan | Reach 100,000 sqm and 3000+ types quick turn PCB per month |
FAQ:
Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber
Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?
Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.
Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).
Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.
Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity
PCB TYPES: Rigid PCB Board, Flex Board, Flex-rigid pcb, PCB Assembly
PCB Production Process:
ABIS with Customer
ABIS cares every your order even 1 piece
